Hey guys so I have decided to start blog series where I will be talking about my experiences in Android! Today I will talking about how I calculated the path of enemy units in the game that I am creating. I would like to note that any code that post in this blog entry is still a work in progress and not all the logic bugs have been worked out but its a great base for anyone trying to figure out how to calculate units paths!
So when I started out thinking about how I was going to figure out the paths of the enemy units I looked at my game map a 2D gird with each cell being 16x16 pixels big. I chose 16x16 because my path sprites are that size and the map will evenly divide by 16. Once I had that figured out I made my towers be 32x32 because it too would evenly fit into the grid.
Now to make all the calculations easy and everything organized I created a class just for handling the everything that has to do with unit paths!
This is what I started off with:
The startX and startY in my code is the "spawn" point of the enemy units and the end vars is the place the units are tying to reach. I also pass the texture I will be using to show the current calculated path to the player. As you may of noticed I divide the starting and ending points by 16. I did this because my cell size is 16x16 so i need to find the x and y in terms of the grid!
The next thing I had to do was to initialize the grid and place the spawn point in the grid.
In this part of the code we can see that I initialized the entire grid to 1. I'm using 1 to define all the movable spots on the map! I also set the spawn point to 0. I did this because in my algorithm 0 is the starting point.
The next thing I added was the method for finding the path and showing in the scene.
With all that code in place I was ready to finally test! This was the result:
This was good and all but I need to calculate a new path every time I added a new tower!
This code allows me to fill the cells where I have towers placed! This was the result when I ran it and added some towers:
Now this was great but there is one more thing that I need to do and that is to check where or not the new tower that I'm placing will block the path of the enemy units.
Well thats all I have so far on this subject! If you have any questions or comments please leave a reply!
Also on a very similar note I am looking for people who may be interested in working with me to create this game! I need people to make sprites for towers and enemy units. I also need someone to create sound effects and original music for this game! If you are interested please PM me or email me!
So when I started out thinking about how I was going to figure out the paths of the enemy units I looked at my game map a 2D gird with each cell being 16x16 pixels big. I chose 16x16 because my path sprites are that size and the map will evenly divide by 16. Once I had that figured out I made my towers be 32x32 because it too would evenly fit into the grid.
Now to make all the calculations easy and everything organized I created a class just for handling the everything that has to do with unit paths!
This is what I started off with:
public class PathManager { private int startX; private int startY; private int endX; private int endY; private ITextureRegion path_sprite_texture; private int [][]grid; private int w; private int h; private List<Sprite>path_sprites; public PathManager(int startX, int startY, int endX, int endY, ITextureRegion path_sprite_texture) { this.startX = startX/16; this.startY = startY/16; this.endX = endX/16; this.endY = endY/16; this.path_sprite_texture = path_sprite_texture; path_sprites=new ArrayList<Sprite>(); } }
The startX and startY in my code is the "spawn" point of the enemy units and the end vars is the place the units are tying to reach. I also pass the texture I will be using to show the current calculated path to the player. As you may of noticed I divide the starting and ending points by 16. I did this because my cell size is 16x16 so i need to find the x and y in terms of the grid!
The next thing I had to do was to initialize the grid and place the spawn point in the grid.
public void initGrid(int width,int height) { w = width/16; h = height/16; grid = new int[h][w]; for(int i=0;i<h;i++) { for(int j=0;j<w;j++) grid[i][j]=1; } grid[startY][startX]=0; }
In this part of the code we can see that I initialized the entire grid to 1. I'm using 1 to define all the movable spots on the map! I also set the spawn point to 0. I did this because in my algorithm 0 is the starting point.
The next thing I added was the method for finding the path and showing in the scene.
public void solveAndShow(Scene s,VertexBufferObjectManager vbo) { solve(); show(s,vbo); revert(); } private void solve() { while(grid[endY][endX]==1) { for (int i = 1; i < h1; i++) { for (int j = 1; j < w1 ; j++) { if (grid[i][j] == 1) { sum(i, j); } } } } int i=endY; int j=endX; while (grid[startY][startX] != 8) { int k = grid[i][j]  1; // cout<<k<<endl; if (grid[i + 1][j] == k) { grid[i][j] = 8; i = i + 1; j = j; continue; } if (grid[i  1][j] == k) { grid[i][j] = 8; i = i  1; j = j; continue; } if (grid[i][j + 1] == k) { grid[i][j] = 8; i = i; j = j + 1; continue; } if (grid[i][j  1] == k) { grid[i][j] = 8; i = i; j = j  1; continue; } } } // this is part of my algorithm. I use a flood type method to find the correct path private void sum(int i,int j) { if ((i1)!=1&&grid[i  1][j] > 1) { grid[i][j] = 1 + grid[i  1][j]; } if ((i+1)<h&&grid[i + 1][j] > 1) { grid[i][j] = 1 + grid[i + 1][j]; } if ((j1)!=1&&grid[i][j  1] > 1) { grid[i][j] = 1 + grid[i][j  1]; } if ((j+1)<w&&grid[i][j + 1] > 1) { grid[i][j] = 1 + grid[i][j + 1]; } } private void show(Scene s,VertexBufferObjectManager vbo) { removeSprites(s); int num=0; for(int i=0;i<h;i++) { for(int j=0;j<w;j++) { if(grid[i][j]==8)// if its 8 then that cell is part of the solved path { s.attachChild(getSprite(i,j,vbo,num)); num++; } } } } // this method reverts the grid to the presolved state private void revert() { for(int i=0;i<h;i++) { for(int j=0;j<w;j++) { if(grid[i][j]==8)// 8 is the solved path grid[i][j]=1; else if(grid[i][j]>=0) grid[i][j]=1; } } grid[startY][startX]=0; } // this method is for removing all the path sprites from the scene private void removeSprites(Scene sc) { for(Sprite s:path_sprites) sc.detachChild(s); } // this method is for getting the sprites to draw. I have the sprites pooled so we dont waste them! private Sprite getSprite(int i,int j,VertexBufferObjectManager vbo,int num) { Sprite s = null; if(num==path_sprites.size()) { s = new Sprite(j*16,i*16,16,16,path_sprite_texture.deepCopy(),vbo); path_sprites.add(s); } else { s = path_sprites.get(num); s.setPosition(j*16,i*16); } return s; }
With all that code in place I was ready to finally test! This was the result:
This was good and all but I need to calculate a new path every time I added a new tower!
public void addObject(int x,int y, int w,int h) { for(int i=y/16;i<(y/16)+(h/16);i++) { for(int j=x/16;j<(x/16)+(w/16);j++) { grid[i][j]=2; } } } public void removeObject(int x,int y, int w,int h) { for(int i=y/16;i<(y/16)+(h/16);i++) { for(int j=x/16;j<(x/16)+(w/16);j++) { grid[i][j]=1; } } }
This code allows me to fill the cells where I have towers placed! This was the result when I ran it and added some towers:
Now this was great but there is one more thing that I need to do and that is to check where or not the new tower that I'm placing will block the path of the enemy units.
private int newNums() { int num = 0; for(int i=0;i<h;i++) { for(int j=0;j<w;j++) { if(grid[i][j]>=0) { num++; } } } return num; } public boolean isBlocking(int x,int y, int w,int h) { boolean blocked = false; int max=1, cmax = 0; this.addObject(x, y, w, h); while(grid[endY][endX]==1&&!blocked) { for (int i = 0; i < this.h ; i++) { for (int j = 0; j < this.w; j++) { if (grid[i][j] == 1) { sum(i, j); } } } cmax = newNums(); if(cmax==max) blocked=true; else max=cmax; } if(grid[endY][endX]==1&&blocked) { revert(); this.removeObject(x, y, w, h); return true; } revert(); this.removeObject(x, y, w, h); return false; }
Well thats all I have so far on this subject! If you have any questions or comments please leave a reply!
Also on a very similar note I am looking for people who may be interested in working with me to create this game! I need people to make sprites for towers and enemy units. I also need someone to create sound effects and original music for this game! If you are interested please PM me or email me!
